The Embedded Winter Challenge

Dec 23, 2022 - Updated: Dec 24, 2022 (CET)

The Embedded Winter Challenge

I got some embedded devices in the past weeks and are starting playing around with hardware since many years again. I do this just for fun, but I really build some useful devices sometimes. Take a look at my blog post about Passkey to see what I actually do.

Devices from the top left to the bottom right:

  • RFID-RC522 SPI based RFID Reader
  • MicroSD SPI based Card Reader
  • MCP2515 SPI based CAN Bus Shield
  • Raspberry Pi Pico RP2040 microcontroller device running MicroPython
  • Arduino Nano ATMega328 based device
  • OLED I²C based Display with SSD1306 Chip 128 x 64 Pixel
  • OLED I²C based Display Module 128 x 32 Pixel
  • Arduino Leonardo Pro Micro ATmega32U4 based device
  • Digispark ATTiny85 based device with micro USB port using the micronucleus bootloader
  • Digispark ATTiny85 based device with USB-A connector using micronucleus
  • RP2040-Zero Pico-Like MCU Board based on Raspberry Pi RP2040 microcontroller
  • CP2102 micro USB to UART TTL Module
  • AT24C256 I²C 256KB EEPROM memory

I own all of these devices more then once so the devices shown above do not all have pin headers soldered on them. It was looking nicer on the photo without headers... ;)

I am getting some more I²C devices in the next days! I am focussing on I²C devices because the I²C protocol is so easy to use, but SPI is interesting too.

For simple stuff I am using Arduino based devices but I really like the RP2040 based devices because I am very familiar with Python and running MicroPython makes so much sense to me. Also I like the possibility to run a REPL to interact with hardware interactively like a command shell. This is a lot of fun and debugging is a lot more easy too.

The UNIX System

Dec 21, 2022 (CET)

The UNIX System

I got the historical book "The UNIX System" from 1983 today! I am impressed. It looks like it is new and it is nearly as old as I am... I always wanted to know more about the good old UNIX days so here I have a book which I believe will be very interesting to read.

Digispark based password store - Passkey

Dec 4, 2022 - Updated: Dec 26, 2022 (CET)

Hello all,

I just started tinkering a bit using an Arduino compatible board named Digispark from Digistump (Since the shop at Digistump is closed actually you have to search for the device on your favorite online marketplaces). I have built this device because I wanted an easy-to-use password store which is cheap and can store more than two passwords like a Yubikey. I really like the Yubikey because it has other nice security features like FIDO2, U2F, Smart card, OTP and OpenPGP 3 protocol support, but they are very expensive if you only want a simple password store. I own three different and also older keys from Yubico just because I wanted to evaluate the different features of all these devices, and I am very happy with them.

Idea

My idea was to build a device with as less code as possible with statically passwords compiled into the binary and acting as a normal keyboard (HID device). The first edition of Passkey just booted and then sent the password to the PC. The second edition got a small button and behaved like the Yubikey. A short press sent the first password, a long press sent the second password. The current and third edition, sends a password after a defined count of button presses. For example, you can edit the code to send a password for the first button press, one for two button presses successively or what ever you decide it should behave. When releasing the last press it takes two seconds to send the desired password which means you need to always have to press the button within two seconds if you want to use more than one presses to get a password. After the last button press the password is printed out after two seconds.

Usage

Just connect the Passkey via USB to your PC and when you will be asked for a password just press the button N times needed for the correct password.

WARNING: Always save your passwords at another secret place, so you can still decrypt, login etc. even when losing your Passkey! I have two Passkeys with the same passwords stored on them where one is stored at a secret place somewhere in this world... ;)

HINT: I always add a prefix or suffix to my passwords which is not stored on the Passkey that I can easily remember for a little more security so when I lose my Passkey all passwords stored on the Passkey are not usable for others. Be sure when using a password suffix, only use "print" and not "println" for getting a password because println will send a newline e.g.: "Enter" / "Return".

HINT: Actually I have problems when using special chars and even when using y,Y,z and Z letters in my passwords because I use my Passkey on several devices with different keyboard layouts. So for me, it only works with numbers from 0-9 and letters from a-x and A-X. But, I think when your password is long enough it should be secure enough. But, if you are using your Passkey in an environment with the same keymap on all devices you should be fine using other chars and letters.

More usage tipps are documented in the code.

Costs

I paid about €3.30 for the Digispark and about €0.30 for the button. Normally I should make use of a Pull-down resistor which will cost some more cents, but for me it works without it.

More ideas and improvements

  • Use the button on pin P5 of the Digispark to make P0, P1 and P2 available for I²C or SPI devices, but I need to re-flash a modified bootloader because P5 is currently configured as RESET pin. Currently, the button uses P0.
  • Add an EEPROM for password storage, but I need to implement a way to store passwords on the device using a serial connection from the PC. Then passwords don't have to be compiled into the binary. I need some kind of management mode for this because by default USB is being used for the HID feature. Maybe I could find a way for implementing this.
  • Delete the passwords in the EEPROM when pressing the button only once. This feature would secure your passwords a little more if you lose your key. So when someone is using your key and presses the button only one time all passwords are erased from the EEPROM.
  • Maybe add an RFID reader via SPI to add more security to only enable getting passwords after enabling the device using a key tag or smart card. Then the device will grow up to a creditcard size.

I believe all feature ideas above will not be possible with this device because of the very limited memory available on the Digispark, but I currently don't know because I didn't tried it. Else I maybe find a "bigger" device for my needs. I think about a Digispark Pro (about €10.00) or better a MicroPython based device using a RP2040 microcontroller (about €4.00 to €14.00; different boards are available)...

If you have some more ideas for Passkey I would like you to contact me... ;)

Sourcecode

The most up-to-date version of the source can always be found here: https://github.com/hanez/arduino/tree/master/Digispark_Passkey. Actually, I didn't looked at the commit history, but I think the first two editions of the Passkey code should be available there too.

// Passkey for Arduino using the Digispark Rev.3 board.
// Copyright 2022 by Johannes Findeisen <you@hanez.org>
// Licensed under the terms of the MIT license.

// For using the Blinker library you have to install it from:
// https://github.com/MajenkoLibraries/Blinker
// Since the code is included in Passkey you easily can just copy
// Blinker/src/Blinker.cpp and Blinker/src/Blinker.h to the root of
// Passkey.
#include "Blinker.h"
#include "DigiKeyboard.h"

// The button pin
#define BUTTON_PIN 0
// The LED pin
#define LED_PIN 1
// The pause after last button press before executing a command
#define PAUSE 2000

// Local variables
unsigned long last;
unsigned int count;

// Create blinker object
Blinker blinker(LED_PIN);

// The list of available passwords
// The number and overall lenght of passwords depends
// because the memory of the digispark is very limited...
// I recommend to use a prefix you easily can remember
// for the password/passwords to make the passwords
// on the passkey unusable for others in case you've lost
// your passkey. E.g.: WhatAWonderfulWorld -> then press the button.
const char *passwords[] = {
  // passwords[0]
  "n0Emb871NAQPSIqBoldh8R7UDaNhncF7Pt60Amdo6GWdTdAPwVBi2A3KU8x8DTCRo6GWdTdXNn2wLh3SUbxVWQvFDVPtatDg",
  // passwords[1]
  "oaxt6e3lSgflOuJ3C6Q6sUb5gvmvI5IEPFku5fqcbxJljBOUblHIT121wCu",
  // passwords[2]
  "jUgKGBtiJ0iNN1Ok9vejrXNn2wLh3SUbxVWQvFDVPtat0OxJlKU8x8DTCRo6GWdTdAPwVBi2A3KUrTKQwjUgK",
  // passwords[3]
  "G57dFnXsPUnRq1eC1CjrGxpCjuiJFlDti54W6wBS9Ro6GWdTdAPwVBi2A3KU8x8KGBtiJ0iNN1Ok9vejrXNn2wLhH"
};

void setup() {
  // Set button pin to high.
  pinMode(BUTTON_PIN, INPUT);
  // Set BUTTON_PIN pin to high because the button is connected
  // to GND when pressed and will go LOW
  digitalWrite(BUTTON_PIN, HIGH);

  // Set blink effect (ON, OFF) in milliseconds
  blinker.setDelay(25, 9075);
  blinker.start();

  // Initialize HID
  DigiKeyboard.delay(0);
  DigiKeyboard.sendKeyStroke(0);

  // Light up the LED for a second to show that passkey is ready
  pinMode(LED_PIN, OUTPUT);
  digitalWrite(LED_PIN, HIGH);
  delay(1000);
  digitalWrite(LED_PIN, LOW);
}

void loop() {
  // Start LED blink effect
  blinker.blink();

  // Read button state
  if (digitalRead(BUTTON_PIN) == LOW) {
    // Button is pressed
    last = millis();
    count++;
    // Wait until button is released
    while (digitalRead(BUTTON_PIN) == LOW) {
      delay(1);
    }
  }

  // Wait PAUSE time before executing a command
  if (count > 0 && (millis() - last) >= PAUSE) {
    // The switch case is the number of button presses
    switch (count) {
      case 1:
        DigiKeyboard.println(passwords[0]);
        break;
      case 2:
        DigiKeyboard.println(passwords[1]);
        break;
      case 3:
        DigiKeyboard.println(passwords[2]);
        break;
      case 5:
        // You can use print instead of println if you don't want
        // to hit enter automatically after inserting the password
        DigiKeyboard.print(passwords[3]);
        break;
      default:
        break;
    }
    // Reset the counter
    count = 0;
  }
}

Source: https://github.com/hanez/arduino/blob/master/Digispark_Passkey/Digispark_Passkey.ino

Found a bug?

Please report bugs here: https://github.com/hanez/arduino/issues

Have fun!

[UPDATE]: I added some more editions of Passkey to the Git repository so you should look at the root of my Arduino repository to get new stuff. In the future I will make Passkey a seperate project because I think this way it will be easier to manage the code.
